Custom Metal Enclosures & Cabinets

Ratings

Bebco designs and manufactures a wide range of custom enclosures, control panels and cabinets for a broad range of applications, to satisfy both domestic and international enclosure standards.

The following information and Website links are provided as a guide to the enclosure design standards that Bebco’s Custom Metallic Enclosures Division can meet or exceed.

The Domestic & International Standards

– The National Electrical Manufacturer’s Association –
Design Standard
NEMA 250
NEMA Website Link: www.nema.org

– The International Electrotechnical Commission –
Design Standard
IEC 60529
IEC Website Link: www.iec.ch

DISCLAIMER: Bebco is not recognized or endorsed by either organization referenced above and information is presented for reference purposes only.

NEMA Rating System

NEMA Type 1: (IP 10)  Indoor use
Provides limited protection against small
amounts of falling dirt

NEMA Type 3: (IP 54)  Outdoor use
Provides limited protection against rain, sleet,
windblown dust and external ice formation

NEMA Type 3R: (IP 14)  Outdoor use
Provides limited protection against rain, sleet
and external ice formation

NEMA Type 4: (IP 56)  Indoor or outdoor use
Provides protection against windblown dust and rain,
splashing or hose-down water and external ice formation

NEMA Type 4X: (IP 56)  Indoor or outdoor use
Provides superior corrosion resistance and protection
(utilizing 316 stainless steel) against windblown dust
and rain, splashing or hose-down water and external
ice formation

NEMA Type 12: (IP 52)  Indoor use
Provides protection against circulating dust,
falling dirt and non-corrosive liquids

NEMA Type 13:  Indoor use
Provides limited protection against dust, sprayed
water, oil and non-corrosive liquids

IP Ratings in parenthesis are NEMA
conversion recommendations

IEC Rating System

IEC Enclosure Ratings are based on a two digit numbering system as listed below.

The first digit indicates a degree of protection against solid particles, and the second digit indicates a degree of protection against liquids.

IP Number Designations

1st Digit – Solid Particles

0  – No protection
– Protection against large foreign bodies
2  – Protection against medium foreign bodies
3  – Protection against small foreign bodies
4  – Protection against granular foreign bodies
5  – Protection from deposit of dust
6  – Protection from access of dust

2nd Digit – Liquids

0  – No protection
1  – Protection against vertical dripping water
2  – Same as 1 above when tilted up to 15 degrees
3  – Protection against sprayed water at 60 degrees
4  – Protection against splashed water
5  – Protection against jetted water
6  – Protection against flooding
7  – Protection in dipped state
8  – Protection in submerged state

Please contact Bebco for more
information regarding IEC Enclosure Ratings

– IMPORTANT NOTE –
The preceding information is provided for reference only, and is not intended
for development or finalization of an enclosure specification.

Contact Bebco or acquire a copy of the referenced NEMA and IEC Standards for the most complete and current information regarding all Enclosure Ratings
